The main functions of each component of the circuit board are as follows
08 Jan,2025
The circuit board is mainly composed of solder pads, vias, mounting holes, wires, components, connectors, fillers, electrical boundaries, etc. The main functions of each component are as follows:
Solder pad: A metal hole used for soldering pins of electronic components.
Through holes: There are metal through holes and non-metal through holes, where metal through holes are used to connect component pins between layers.
Installation hole: used to fix the circuit board.
Wire: An electrical network copper film used to connect component pins.
Connector: A component used for connecting circuit boards.
Fill: Copper coating used for ground wire networks can effectively reduce impedance.
Electrical boundary: used to determine the size of the circuit board, and all components on the circuit board must not exceed this boundary.
